Stationary belt conveyor KLS
USING
Stationary belt conveyors KLS are designed for transportation of granular materials with an angle of natural slope of not more than 60° and humidity of not more than 4% in a horizontal or inclined direction of up to 15° in industrial premises at an ambient temperature of -30° to 50°.
technical specifications
| Parameters | Conveyor KLS-500 | Conveyor KLS-650 | Conveyor KLS-800 | Conveyor KLS-1000 |
|---|---|---|---|---|
| Belt width, mm | 500 | 650 | 800 | 1000 |
| Belt speed, m/s | up to 1,5 | up to 1,5 | up to 1,5 | up to 1,5 |
| Rated output, m3/h | up to 80 | up to 100 | up to 150 | up to 220 |
| Driving drum diameter, mm | 315...420 | 315...500 | 315...500 | 500 |
| Tension drum diameter, mm | 315 | 315 | 315 | 420 |
| Belt type | 500 EP 400/3 4/2 Y | 650 EP 400/3 4/2 Y | 800 EP 400/3 4/2 Y | 1000 EP 400/3 4/2 Y |
| Roller carriage design | 2-roller grooved | 3-roller grooved | 3-roller grooved | 3-roller grooved |
| Type of motor reduction unit | cone-parallel UD-KA | cone-parallel UD-KA | cone-parallel UD-KA | cone-parallel UD-KA |
| Driving position | right / left | right / left | right / left | right / left |
| Tensioning device type | screw / take up by gravity | screw / take up by gravity | screw / take up by gravity | screw / take up by gravity |
| Electric power supply voltage, V | 380 ± 38 | 380 ± 38 | 380 ± 38 | 380 ± 38 |
| Electrical frequency, Hz | 50 ± 1 | 50 ± 1 | 50 ± 1 | 50 ± 1 |
